N°95275 · Family detail
SigmaWide·CANON EF mount·2003
Sigma 12-24mm F/4.5-5.6 EX DG ASPH [HSM]
Specifications01
MountCANON EF
Focal length12-24mm
Max aperturef/4.5
TypeWide · Zoom
Release year2003
Weight615 g
Physical length103 mm
Min focus distance0.28 m
Max magnification0.1408
Aperture blades6
Optical elements16
Groups12
Min aperturef/5.6
AutofocusYes
StabilizationNo
Aperture controlNone
The aperture is controlled from the camera(Canon EF, Minolta/Sony A, Sigma SA)
Aperture ring (Manual settings + Auto Exposure setting)(Nikon F, Pentax K)
Lens hoodBuilt-in petal-shaped
TeleconvertersNot compatible
EraDigital era
Production statusDiscontinued
Additional Info02
Lens TypeWide-angle zoom lens
Summary02
Sigma 12-24mm zoom lens for Canon EF, with a maximum aperture range of f/4.5-5.6. Designed for wide-angle applications such as landscapes and architecture.
AI-assisted summary — verify against linked sourcesWhere can this lens be adapted?
The Canon EF mount has a flange distance of 44 mm. A plain adapter fits a camera whose flange distance is at least 1.46 mm shorter. How lens adapters work
- Native lenses set the aperture, and often the focus, electronically. On a plain adapter they do not work. Use an electronic adapter made for this pair; for many pairs nobody makes one. Fully manual lenses are the exception.
- Sony EAdapter · 26 mm
The camera mount (46.1 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Canon RFAdapter · 24 mm
- Nikon ZAdapter · 28 mm
- Fujifilm XAdapter · 26.3 mm
- L-MountAdapter · 24 mm
The camera mount (51.6 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Micro Four ThirdsAdapter · 24.75 mm
- Fujifilm G (GFX)Adapter · 17.3 mm
Covers full-frame: it can vignette on a medium format sensor.
- Canon EF-MAdapter · 26 mm
- Canon EFNative
No plain adapter reaches infinity focus on: Nikon F.
![Sigma 12-24mm F/4.5-5.6 EX DG ASPH [HSM]](https://img.lens-database.com/lenses/variants/v1/c6bafde7b5f63cd3e6b5fd21c6f4a17e8e910a66b03892cd61833fed2c6ac6a0/dbfd9c6f2bdb2ae4a36d607a6302cc2f1e6a4d991753db82e437cc0638a54514/599x399/1280.webp)
Other Mounts03
This lens family is also indexed in 3 other mounts.
