N°8678816 · Family detail
SigmaTelephoto·CANON EF mount·1999
Sigma 800mm F/5.6 APO EX [HSM]
Specifications01
MountCANON EF
Focal length800mm
Max aperturef/5.6
TypeTelephoto · Prime
Release year1999
Weight4440 g
Min focus distance7 m
Max magnification0.1136
Aperture blades9
Optical elements12
Groups9
AutofocusYes
StabilizationNo
Aperture controlNone
The aperture is controlled from the camera(Canon EF, Minolta/Sony A, Sigma SA)
Aperture ring (Manual settings + Auto Exposure setting)(Nikon F, Pentax K)
TeleconvertersSigma APO Tele Converter 1.4x EX→ 1120mm F/7.8
Sigma APO Tele Converter 1.4x EX DG→ 1120mm F/7.8
Sigma APO Tele Converter 2x EX→ 1600mm F/11.2
Sigma APO Tele Converter 2x EX DG→ 1600mm F/11.2
EraFilm era
Production statusDiscontinued
Additional Info02
Lens TypeSuper telephoto prime lens
Summary02
Sigma 800mm f/5.6 APO EX telephoto lens for Canon EF. It’s designed for distant subjects such as sports or wildlife, using autofocus (HSM) and a fixed maximum aperture of f/5.6.
AI-assisted summary — verify against linked sourcesWhere can this lens be adapted?
The Canon EF mount has a flange distance of 44 mm. A plain adapter fits a camera whose flange distance is at least 1.46 mm shorter. How lens adapters work
- Native lenses set the aperture, and often the focus, electronically. On a plain adapter they do not work. Use an electronic adapter made for this pair; for many pairs nobody makes one. Fully manual lenses are the exception.
- Sony EAdapter · 26 mm
The camera mount (46.1 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Canon RFAdapter · 24 mm
- Nikon ZAdapter · 28 mm
- Fujifilm XAdapter · 26.3 mm
- L-MountAdapter · 24 mm
The camera mount (51.6 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Micro Four ThirdsAdapter · 24.75 mm
- Fujifilm G (GFX)Adapter · 17.3 mm
Covers full-frame: it can vignette on a medium format sensor.
- Canon EF-MAdapter · 26 mm
- Canon EFNative
No plain adapter reaches infinity focus on: Nikon F.
![Sigma 800mm F/5.6 APO EX [HSM]](https://img.lens-database.com/lenses/variants/v1/ceec6f4291c36dbc7a257a129193de7852106a5a95db509911ba30bd1b136778/d2b4a482d8d77637b9a42a43c4f84d2747be761be01e3495c8b908de65054735/1600x1071/1280.webp)
Other Mounts03
This lens family is also indexed in 2 other mounts.
