N°420367 · Family detail
PentaxWide·PENTAX K mount·2004
Smc Pentax-DA 14mm F/2.8 ED
Specifications01
MountPENTAX K
Focal length14mm
Max aperturef/2.8
TypeWide · Prime
Release year2004
Weight420 g
Filter size77 mm
Min focus distance0.17 m
Max magnification0.1901
Aperture blades6
Optical elements12
Groups11
AutofocusYes
StabilizationNo
Aperture controlNone
The aperture is controlled from the camera
Lens hoodPH-RBH77 - Bayonet-type petal-shaped
With filter access window
TeleconvertersHD Pentax-DA 1.4X AF Rear Converter AW→ 19.6mm F/3.9
EraDigital era
Production statusDiscontinued
Additional Info02
Lens TypeUltra-wide angle prime lens
Summary02
Pentax K-mount wide-angle prime lens with a 14mm focal length and f/2.8 maximum aperture, intended for landscape, architecture, and general wide-angle low-light use. (DA marking indicates APS-C use.)
Where can this lens be adapted?
The Pentax K mount has a flange distance of 45.46 mm. A plain adapter fits a camera whose flange distance is at least 1.46 mm shorter. How lens adapters work
- Pentax DA and FA J lenses have no aperture ring. Use an adapter with its own aperture control.
- Pentax DA lenses are made for APS-C.
- Sony EAdapter · 27.46 mm
- Canon RFAdapter · 25.46 mm
- Nikon ZAdapter · 29.46 mm
- Fujifilm XAdapter · 27.76 mm
- L-MountAdapter · 25.46 mm
- Micro Four ThirdsAdapter · 26.21 mm
- Fujifilm G (GFX)Adapter · 18.76 mm
- Canon EF-MAdapter · 27.46 mm
- Canon EFAdapter · 1.46 mm
A rear element that sticks out can hit the camera mirror.
No plain adapter reaches infinity focus on: Nikon F.
Other Mounts03
No alternate mounts are indexed for this family yet.
