N°310510 · Family detail
SigmaWide·CANON EF mount·2015
Sigma ART DG HSM 20mm F/1.4
Specifications01
MountCANON EF
Focal length20mm
Max aperturef/1.4
TypeWide · Prime
Release year2015
Weight950 g
Physical length129.5 mm
Barrel diameter91 mm
Min focus distance0.277 m
Max magnification0.14
Aperture blades9
Optical elements15
Groups11
Min aperturef/16
AutofocusYes
StabilizationNo
Weather sealedNo
Sensor coverage43.3 mm
Approx price$819
Additional Info02
TypeWide-angle prime
ModelDG HSM
FormatFull Frame
SeriesART
SpecialHSM
Lens TypePrime lens
Iris Blades9
Angle Of View94.5°
Country Of OriginJapan
Summary02
Sigma 20mm f/1.4 ART DG HSM wide-angle prime for Canon EF. Designed for APS-C/FF full-frame use with a large fixed aperture for low-light and general wide-angle photography.
AI-assisted summary — verify against linked sourcesWhere can this lens be adapted?
The Canon EF mount has a flange distance of 44 mm. A plain adapter fits a camera whose flange distance is at least 1.46 mm shorter. How lens adapters work
- Native lenses set the aperture, and often the focus, electronically. On a plain adapter they do not work. Use an electronic adapter made for this pair; for many pairs nobody makes one. Fully manual lenses are the exception.
- Sony EAdapter · 26 mm
The camera mount (46.1 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Canon RFAdapter · 24 mm
- Nikon ZAdapter · 28 mm
- Fujifilm XAdapter · 26.3 mm
- L-MountAdapter · 24 mm
The camera mount (51.6 mm) is narrower than the lens mount (54 mm). A large rear element can darken the corners.
- Micro Four ThirdsAdapter · 24.75 mm
- Fujifilm G (GFX)Adapter · 17.3 mm
Covers full-frame: it can vignette on a medium format sensor.
- Canon EF-MAdapter · 26 mm
- Canon EFNative
No plain adapter reaches infinity focus on: Nikon F.
Other Mounts03
This lens family is also indexed in 5 other mounts.
